HE01 H.264 HDMI encoder for IP TV
FX-HE01
1 Feature
l Support H.264 encoding
l Support UDP, HTTP, RTSP, RTMP, ONVIF protocol.
l Support MPEG1 Audio Layer 2.
l CBR/VBR rate: 16Kbps~16Mbps.
l 1000M network interface uses full duplex mode.
l Support up to 720p, 1080p@60HZ HD video input.
l Support image parameter settings.
l WEB interface management authority.
l Support remote management in WAN (WEB).
l Support resolution customized settings.
l Support one key to restore the factory configuration.
l Power consumption: 5W
l Dimension (L×W×H):104.5x79x28.5mm
l Net Weight:275g
2 SPECIFICATIONS
|
Operating Temperature Range |
-5 to +65℃(+23 to +149℉) |
|
Operating Humidity Range |
5 to 90%RH (No Condensation) |
|
Output Video Format |
TS/VES/AES |
|
encoder |
H.264 |
|
Input resolution |
720p, 1080p@60HZ |
|
CBR/VBR rate |
16Kbps~16Mbps |
|
Bandwidth |
10.2Gbps |
|
Power consumption |
5watts |
|
Dimension (L×W×H) |
104.5*79*28.5mm |
|
Net Weight |
275g |
CONNECT AND OPERATE
(1) Connect the HDMI signal sources (Such as Industry HD Camera, PlayStation 4, Xbox 360 etc).
(2) Connect the HDMI Output (Such as Computer, TV).
(3) Connect the DC 5V1A power supply.
